MicroFreak - General Questions

sidechain_fet
Do you have questions about MicroFreak?
You will likely find an answer here:

The oscillators modes are a panel of different algorithms, which lets MicroFreak generate a wide variety of sounds.
The algorithms are:


filtermodes
Find below the brand new algorithms built by our team in Arturia Headquarters:
filtermodes
Virtual analog, recreating traditional synth methods digitally for a mix of classic and cutting-edge tones.
filtermodes
Precisely detuned saw, square, sine, or triangle waves let you create the fattest synth sounds around. Perfect for Trance and lush dreamy pads.
filtermodes
Synthesize your sound from 32 sine waves by modulating their volume. The clue is in the name, it creates harmonically rich, vibrant sounds which can be shaped with the filter.
filtermodes
A much-loved synth method using physical modelling to recreate the sound of string instruments, from soft pizzicato to screeching, zingy chords.
filtermodes
Scan through waveform snapshots to find new, unusual, and evolving sounds. It contains 16 wavetables to explore, with room for more in the future.
filtermodes
We’ve also integrated the open-source Plaits oscillator developed by Eurorack legends Mutable Instruments to bring you 7 additional synth modes.
filtermodes
A triangular wave, processed by waveshaping and wavefolding creating squelchy, aggressive, and often metallic tones.
filtermodes
A simple but powerful twin-operator FM oscillator, with two sine waves modulated each other’s phase to create sharp, acidic tones.
filtermodes
A percussive, granular synthesis engine that is great for adding huge texture and body to sequenced rhythms.
filtermodes
A paraphonic synth engine that triggers duplicates at set intervals, creating defined, static chords with one key, perfect for trance-inspired melodies.
filtermodes
An engine that creates vowel, formant, and simple word sounds. Automate with the mod matrix, and hear MicroFreak come alive!
filtermodes
Recreates the unique inharmonic vibrations and resonance of a hollow structure. Perfect for adding texture, or bizarre overtones to your music.
The Spice and Dice function works together to let you alter an existing sequence and create an ephemeral variation of it.

It acts on the gates, triggers, velocity, decay and release of the current Arpeggio or Sequence, and randomizes them. It can for example change the distance between two triggers, shorten or lengthen the gates or even mute them.

Spice

Determines how much a Dice throw will alter the sequence.
To change its value, select the Spice and set an amount with the touch strip.

Dice

Modifies the sequence depending of the amount of Spice defined.
To change its value, select the Dice and set an amount with the touch strip.

In monophonic mode, the Digital Oscillator generates a waveform, which is then sent to the Filter and an analog VCA.

Amplitude Envelope ON

comb_feedback
When the Amp Mod button is ON, the ADSR envelope is hardwired to the analog VCA.

Amplitude Envelope OFF

filter_2
When the Amp Mod button is OFF, the keyboard Gate signal controls the VCA.

Note: In Paraphonic mode with Amp Mod ON the envelope is duplicated several times depending on the number of voices you have specified in Utility.
These envelopes control a number of internal digital VCAs that only become active in Paraphonic mode.

MicroFreak is a paraphonic four-voice synthesizer.
It means that all four voices can be triggered independently, but are sharing the same filter.

Unlike most other paraphonic synths, each voice can have its own amplitude level.
Additionally, some of the MicroFreak modulators are polyphonic, like the main Envelope, the Pressure, the Keyboard, and the Arpeggiator.
When applied to polyphonic destinations, like the parameters of the oscillators for example, each modulation value will be independent from each other.


Note: When applied on a monophonic destination, like the filter cutoff, the value of the parameter will be overwritten by the latest modulation value received.

comb_feedback
MicroFreak lets you either change the keyboard response from Pressure to Velocity.
Both modes are polyphonic, which means that each note can have it's own Velocity or Pressure value.

Velocity

The velocity value is defined by the speed at which your finger touches the keyboard.

Pressure

The Pressure value varies with the surface area of your finger in contact with the keyboard.

comb_feedback
MicroFreak can send MIDI from its controls and receive MIDI from a DAW or any controller.
Please find below the list of each parameter, with its associated MIDI message.
FUNCTIONS AND MIDI PARAMETERS
Function MIDI Message Range
Glide CC5 0-127
Type CC9 10-127
Wave CC10 0-127
Timbre CC12 0-127
Shape CC13 0-127
Cutoff CC23 0-127
Resonance CC83 0-127
Cycling Env Rise CC102 0-127
Cycling Env Fall CC103 0-127
Cycling Env Hold CC28 0-127
Cycling Env Amount CC24 0-127
ARP/SEQ Rate (free) CC91 0-123
ARP/SEQ Rate (sync) CC92 0-127
LFO Rate (free) CC93 0-127
LFO Rate (sync) CC94 0-127
Envelope Attack CC105 0-127
Envelope Decay CC106 0-127
Envelope Sustain CC29 0-127
Keyboard Hold button (toggle) CC64 0-127
Keyboard Spice CC2 0-127
Keyboard Pitch Bend Pitchbend 0-127
Keyboard Pressure Aftertouch 0-127
Note:
The MicroFreak has its own proprietary Multi-Client USB driver.
On Windows, this makes the usage of the MicroFreak possible on multiple applications at the same time.
MicroFreak can receive program changes from USB and MIDI Din.
Please see below how Bank and Program change messages are handled.
PROGRAM CHANGE AND BANK MESSAGES HANDLING
Function Bank Program Change
Preset 1 to 128 Bank 1 0 to 127
Preset 129 to 256 Bank 2 0 to 127
comb_feedback

Ground

A convenient advantage of the MicroFreak is that it can be USB powered.
However, its touch capacitive keyboard needs a proper grounding to work flawlessly.

Don't worry, in most situations, the keyboard will be working fine.
But if you encounter some irregular pitch changes when playing on the keyboard, or any strange behavior when pressing the arp buttons and touch strip, please power it using a grounded power supply (three pin wall plug) or a USB grounded device.

If you have any further questions, feel free to contact us.
