01
Check out some RackBrute tips and tricks.


Below, you will find the RackBrute assembly guide from the instructions manual.
You will need the following screws & washers to assemble your RackBrute:

rackbrute screws


quickstart rackbrute6u v3

Note: To add a second RackBrute or a MiniBrute 2 to your Ecosystem, repeat the steps 3 to 7.


Find below a few steps explaining how to install a new module on your RackBrute:


1. Disconnect the power supply from your RackBrute.


2. Check your module manual or documentation and make sure it doesn't have any particular way to be connected.


3. Connect the ribbon cable to your module following it's documentation.
(This cable should be supplied with your module.)

rackbrute install module 3.3

Note: The cable should have a red stripe on one of it"s side.
This red line always represent the -12V, which must always line up with -12V on the module socket.


4. Connect the ribbon cable to the RackBrute bus board.

rackbrute install module 2

Note: The cable should have a red stripe on one of it"s side.
This red line always represent the -12V, which must always line up with -12V on the bus board.


5. Install the module on the RackBrute rail with the provided screws (black) and washers (transparent).

rackbrute install a module 1 1

The RackBrute ecosystem offers various layout possibilities.
This allows your RackBrute & MiniBrute to either fit nicely in your studio, or in any live gig.
Please find below some concrete examples:

3u special6u 26u 56u 66u special6u verticalkeyboard 1seq


If you have any further questions, feel free to contact us.
